Shipping Length Of Unit
27.96ft in
Shipping Height Of Unit
9.42ft in
Max Cutting Height
28.84ft in
Max Loading Height
20.25ft in
Max Reach Along Ground
27.96ft in
Max Vertical Wall Digging Depth
16.05ft in
Max Digging Depth
18.57ft in
Boom/Stick Option (Hex) 1
Boom 16’11” (5150mm)/Stick 7’5″ (2250mm)
Boom/Stick Option (Hex) 2
Shipping Length Of Unit
27.89ft in
Max Cutting Height
28.97ft in
Shipping Height Of Unit
9.29ft in
Max Loading Height
20.41ft in
Max Reach Along Ground
28.86ft in
Max Vertical Wall Digging Depth
16.9ft in
Max Digging Depth
19.85ft in
Boom/Stick Option (Hex) 2
Boom 16’11” (5150mm)/Stick 8’7″ (2620mm)
Boom/Stick Option (Hex) 3
Shipping Length Of Unit
27.89ft in0
Max Cutting Height
29.37ft in
Max Loading Height
20.87ft in
Shipping Height Of Unit
9.59ft in
Max Reach Along Ground
29.79ft in
Max Vertical Wall Digging Depth
17.67ft in
Max Digging Depth
20.81ft in
Boom/Stick Option (Hex) 3
Boom 16’11” (5150mm)/Stick 9’6″ (2900mm)
Dimensions
Ground Clearance
1.45ft in
Height To Top Of Cab
9.26ft in
Width To Outside Of Tracks
8.17ft in
Length Of Track On Ground
9.45ft in
Tail Swing Radius
8.03ft in
Removal Counterweight Clearance
3.22ft in
Undercarriage
Track Gauge
6.53ft in
Shoe Size
19.69in
Ground Pressure
7psi
Max Travel Speed
3.42mph
Specifications
Engine
Number Of Cylinders
6
Engine Make
2238
Engine Model
S6D95L
Gross Power
99.3hp
Power Measured @
2000rpm
Displacement
298.5cu in
Operational
Operating Weight
33907.1lb
Fuel Capacity
60.8gal
Hydraulic System Fluid Capacity
35.7gal
Hydraulic System Relief Valve Pressure
4620psi
Hydraulic Pump Flow Capacity
73gal/min
Swing Mechanism
Swing Speed
12rpm
Buckets
Reference Bucket Capacity
0.9yd3
Minimum Bucket Capacity
0.8yd3
Maximum Bucket Capacity
1yd3
